500W, 1000W, 500W pure sine wave hybrid inverter feature a solar controller and AC charging function, providing stable power for home appliances, outdoor activities, and emergency backup. With AC charging, portability, and comprehensive protection features, they are perfect for a variety of applications.
| color | White/blue/Green/orange |
|---|---|
| AC input | 110VAC/120VAC/220VAC/230VAC/240VAC(option) |
| AC output | 110VAC/120VAC/220VAC/230VAC/240VAC(option) |
| DC Voltage（Battery ） | 12VDC or 24VDC（option) |
This hybrid inverter is equipped with a solar controller and AC charging function, making it a versatile and reliable power solution. With power ratings of 500W, 1000W, and 1500W, it offers a wide range of applications and advantages.
Designed for home environments, this hybrid inverter provides stable power for household appliances such as lights, TVs, and computers. It is especially suitable for use with solar panels, harnessing clean energy and reducing reliance on traditional power sources.
Whether you’re camping or engaging in outdoor activities, this hybrid inverter is your perfect companion. It offers power support for outdoor lights, electronic devices, and more, making your outdoor experience practical and convenient.
In times of power outages or emergencies, this hybrid inverter serves as a reliable backup power source. It ensures continuous power supply for critical equipment like communication devices and medical equipment, providing peace of mind during unforeseen circumstances.
Portable Devices
With its portable design, this hybrid inverter is ideal for mobile power needs. Whether you’re on an RV or a boat, it can provide power for your mobile devices, keeping you connected and powered up wherever you go.
AC Charging Function
In addition to its solar capabilities, this hybrid inverter can also charge its internal battery via AC power. This feature ensures timely charging of backup power sources and uninterrupted power supply.
Energy Saving and Environmental Protection
By utilizing clean energy from solar panels, this hybrid inverter promotes energy saving and environmental protection. It reduces dependence on traditional energy sources, lowers energy costs, and contributes to a greener and more sustainable future.
Comprehensive Protection Features
Equipped with overload protection, short circuit protection, overvoltage protection, undervoltage protection, and more, this hybrid inverter ensures the safe operation of both the inverter and the devices it powers.
In conclusion, this hybrid inverter offers various applications and advantages, making it suitable for different occasions and needs. It provides users with a convenient and stable power solution, enhancing their overall power experience.
Comprehensive Information Display: The LCD display provides a comprehensive view of the inverter’s operating parameters, including input and output voltage, frequency, battery voltage, and battery capacity percentage, allowing users to easily monitor these important metrics.
Operational Mode Display: The LCD screen shows the inverter’s operational mode, such as battery mode, mode selection, and generator mode, enabling users to monitor the inverter’s operating status at all times.
Customizable Settings: Users can easily adjust the inverter’s settings through the LCD display, such as selecting the battery mode and operational mode, enabling more intelligent operation.
Solar Power Display: The LCD screen clearly shows the amount of power being generated by the solar panels, allowing users to track the system’s efficiency and performance.
Voltage and Current Display: The screen also displays the solar panel’s voltage and current, providing users with detailed insights into the system’s electrical characteristics.
Real-time Monitoring: Users can monitor solar power generation in real time, enabling them to optimize energy usage and maximize efficiency.
User-Friendly Operation: The LCD display is user-friendly, allowing users to easily understand and operate the inverter, ensuring smooth and efficient operation of the device.
Inverter features a rear panel design with several notable characteristics:
1.High-Current Battery Terminals: The device is equipped with high-current battery terminals, ensuring safe and reliable battery connections. These terminals support the connection of high-power battery systems, catering to various needs.
2.High-Speed Cooling Fan: The rear panel is equipped with a high-speed cooling fan that effectively dissipates heat, maintaining stability during high-load operations and prolonging the device’s lifespan.
3.Easy Wiring: The device’s design prioritizes user convenience, with simple and easy wiring connections. Users can quickly complete the installation and connection of the inverter.
pure sine wave hybrid solar inverter install connection
Technical Data Sheet：
| Model: | 300W | 500W | 700W | 800W | 1000W | 1200W | 1500W | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated power: | 300W | 500W | 700W | 800W | 1000W | 1200W | 1500W | |||||
| Peak power: | 600W | 1000W | 1400W | 1600W | 2000W | 2400W | 3000W | |||||
| AC input voltage range: | 70V-135VAC(110VAC/120VAC) 140V-275VAC(220VAC / 230VAC ) | |||||||||||
| Input frequency range: | 45-65HZ | |||||||||||
| Battery voltage: | 12VDC /24VDC | 24VDC | ||||||||||
| DC voltage： | 12VDC:10.5-15VDC/ 24VDC:21-30VDC | |||||||||||
| solar controller： | 10A | 20A | 30A | |||||||||
| Solar input： | 120W | 240W/480W | 360W/720W | |||||||||
| Battery undervoltage alarm: | 10.5VDC /21VDC | |||||||||||
| Battery undervoltage protection: | 10VDC /20VDC | |||||||||||
| Battery overvoltage protection: | 17V±0.5V /34V±0.5V | |||||||||||
| Voltage overvoltage alarm: | 15V-16VDC/30V-32VDC | |||||||||||
| Overload protection: | Rated power of 110% or more | |||||||||||
| Temperature protection: | ≥ 85 ℃ alarm, ≥ 90 ℃ off the machine | |||||||||||
| Inverter output voltage: | 110VAC/120VAC/ 220VAC/230VAC±2% | |||||||||||
| Inverter output frequency: | 50/60HZ±10% | |||||||||||
| Inverter output waveform: | pure sine wave | |||||||||||
| AC output voltage range: | AVR output 110VAC/120VAC/ 220VAC/230VAC±10% | |||||||||||
| Output frequency range: | Automatic tracking | |||||||||||
| Conversion time: | 5ms-10ms | |||||||||||
| Cooling method: | Intelligent fan control, ≤ 42 ℃ fan slow working , ≥ 45 ℃ fan high working . | |||||||||||
| AC Charging current: | 20A | |||||||||||
Working mode selection: | Free to choose(SET) 01: AC priority/City power priority: When city power is available, the inverter will work AC output, city power will supply power to appliances.The city power and sun power will charges 2 kinds power to battery. When city power failed, sun power will charges the battery and use battery power(solar power) to take the appliances. 02: energy saving mode load power ≤ 10% off the machine, ≥ 11% -100% turn on 03: Battery priority When it have sun power, sun power charges the battery and supply power to the appliances. When it does not have sun power or battery voltage ≤10.5V, inverter will automatic use city power to take the appliances, When battery voltage reach 13V inverter will use use battery power and sun power. | |||||||||||
| External Size(mm) D×W×H | 290*310*135mm | |||||||||||
| Packing Size(mm) D×W×H | 415*380*225mm | |||||||||||
| Net Weight(kg) | 11 | 13 | 14 | 16 | 18 | 20 | 22 | |||||
| Gross Weight(kg) | 13 | 15 | 16 | 18 | 20 | 22 | 24 | |||||
