4KW, 5KW and 6KW pure sine wave transformer based Full Protection Features With AC charger UPS inverter can be used as backup power supply to provide power for critical equipment, such as medical equipment, communication equipment, etc.it ensures that the backup battery is fully charged at any time.
color | White/blue/Green/orange |
---|---|
AC input | 110VAC/120VAC/220VAC/230VAC/240VAC(option) |
AC output | 110VAC/120VAC/220VAC/230VAC/240VAC(option) |
DC Voltage(Battery ) | 48VDC or 96VDC |
1.Stability and Reliability:They can adapt well to different types of loads, including inductive loads and capacitive loads, which makes them more flexible in various application scenarios.For example, application scenarios that require continuous power supply, such as hospitals, factories, and data centers.
2.Full Protection Features: With comprehensive protection features, including overload protection, short-circuit protection, over-voltage protection, and more, our inverters ensure the safety of connected devices and the inverter itself.
3. UPS Functionality: The UPS functionality allows for uninterrupted power supply, making our inverters ideal for critical applications where downtime is not an option(DC To AC Auto).
4.Built-in Big AC Charging: The built-in AC charging feature adds convenience and flexibility, allowing users to charge their batteries directly from the inverter.
Uses and advantages:
Home Applications: These 4KW5KW6KW inverters are suitable for home applications and can provide stable and reliable power to the home, powering home equipment such as TVs, refrigerators, air conditioners, etc. The advantage is that its pure sine wave output can protect sensitive electronic equipment, and it also has a mains charging function to facilitate the charging of spare batteries.
Commercial Applications: In commercial applications, these inverters can provide power to small commercial buildings, shops or offices, powering POS systems, computers, printers and other equipment. The advantage lies in reliable power output and mains charging function, ensuring the normal operation of the equipment and the timely charging of the backup battery.
Outdoor activities and mobile offices: These inverters are also suitable for outdoor activities, campers, boats, etc., and can power outdoor equipment such as lamps, ovens, TVs, etc. The advantage lies in its mobility and mains charging function, which can charge devices at any time to ensure the convenience and comfort of outdoor activities.
Backup power supply: In case of sudden power outage or emergency, these inverters can be used as backup power supply to provide power for critical equipment, such as medical equipment, communication equipment, etc. The advantage lies in its mains charging function, which ensures that the backup battery is fully charged at any time.
Sustainable Energy Applications: These inverters can also be used with solar panels to convert solar energy into electrical energy for power supply. Its mains charging function can be used to charge solar battery packs, improving energy efficiency.
In general, 4KW, 5KW and 6KW pure sine wave power frequency inverters have mains charging function and are suitable for various application scenarios such as home, business, outdoor and emergency backup power supply. They have reliable power output and flexible Mains charging function provides stable and reliable power solutions for various scenarios.
Model | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | 8000W | 10000W | 12000W | |
---|---|---|---|---|---|---|---|---|---|---|---|
Input | Rated capacity | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | 8000W | 10000W | 12000W |
peak power | 3000W | 4500W | 6000W | 9000W | 12000W | 15000W | 18000W | 24000W | 30000W | 36000W | |
Commercial Power range | 110VAC:83V-137VAC 120VAC:90V-150V | 220VAC:176V-264VAC | |||||||||
220VAC:165V-275VAC 230VAC:173V-287V | 230VAC:184V-276V | ||||||||||
AC frequency range | 45-65HZ | ||||||||||
Battery | Type | lead-acid battery / GEL battery / lithium battery | |||||||||
DC Voltage | 12 VDC /24VDC | 24VDC/48VDC | 48VDC/96VDC | ||||||||
Input voltage range | 12VDC:10.5-15VDC 24VDC:21-30VDC 48VDC:42-60VDC 96VDC:84-120VDC | ||||||||||
Floating charge set | 12.9 ~ 13.6 V(1PCS battery) can be set | ||||||||||
Low voltage restored | 12VDC:12.6-14.4VDC 24VDC:25.2-28.8VDC 48VDC:50.4-57.6VDC 96VDC:100.8-115.2VDC | ||||||||||
Low voltage shutdon set | 12VDC:10-10.9V 24VDC:20-21.8V 48VDC:40-43.6V 96VDC:80V-87.2V | ||||||||||
over voltage protection | 12VDC:16.7VDC 24VDC:33.4V 48VDC:66.8V | ||||||||||
over voltage alarm | 12VDC:15VDC 24VDC:30V 48VDC:60V | ||||||||||
Charger | AC charging | 5A-30A(40A, 50A, 60A,70A Optional) | |||||||||
Output | Capable of starting electric motor | 0.5HP | 1HP | 1.5HP | 2HP | 3HP | |||||
AVR voltage range(VAC) | 110/120/220/230/240±10%(Auto-sensing) | Without | |||||||||
Transfer time | Typical:5ms(Including detection time) | ||||||||||
Temperature protection | ≥85℃ alarm ≥90℃ machine shut off | ||||||||||
overload | IPS automatically shut down if overload exceeds 120% of normal value for 10 seconds, IPS automatically resume work if overload comes to rated load. | ||||||||||
Waveform | Pure sine wave | ||||||||||
Frequency | Commercial power supply: shared frequency with the commercial inversion state:60/50±0.5 | ||||||||||
Output frequency range | Tracking automatically | ||||||||||
(electric supply mode) | |||||||||||
temperature | Operating Temperature | 0℃~70℃ | |||||||||
Thermal method | Cooling fan in intelligent control≤42℃ fan rotates slowly to ≥45℃ fan rotates fast | ||||||||||
Appearance | External Size(mm) | 510*295*225mm | 680*295*225mm | 765*320*250mm | |||||||
(L*W*H) | |||||||||||
Gross Size(mm) | 550*350*255mm | 740*360*275mm | 830*380*310mm | ||||||||
(L*W*H) | |||||||||||
Net weight(kg) | 13 | 14 | 17 | 19 | 26 | 27 | 28 | 47 | 50 | 52 | |
Gross weight(kg) | 16 | 17 | 20 | 22 | 29 | 30 | 31 | 51 | 54 | 56 |
